l Merits产品特点
- 光斑小,发散角小
- 高稳定性,高可靠性
- 静电,过流,过温保护,保障激光器使用寿命
- 适合全球不同环境温度下使用
l Specification产品规格
Model 型号 | LWRM785-500 |
Wavelength 波长(nm) | 785 |
Max Output power 输出功率(mW) | 500 |
Power adjust 功率调节(mW) | 0-Pmax |
Operating mode 工作模式 | CW,TTL |
Power stability 功率稳定性(rms, over 4 hours) | <1%、<3% |
Fiber core diameter 光纤芯径(um) | 105,200,400,600等其他芯径按要求定制 |
Spectral line width 线宽(nm) | 0.06 |
NA of fiber 数值孔径 | 0.22 |
Length of fiber 光纤长度(m) | 1 or 1.5 其他长度按要求定制 |
Connector of fiber 接头 | SMA905 其他接头可选(FC/SC/ST) |
Working temperature 工作温度(℃) | 0-40 |
TTL modulation frequency 调制频率(kHz) | <30 |
Expected life time 寿命(h) | 10000 |
